5.56m 6.23m T Model Prefab House C Section Prefab Steel Homes

Place of Origin : Shandong

Brand Name : Lida

Certification : ISO / CE

MOQ : 500 sq

Payment Terms : L/C, T/T

Feature : Soundproof/ Rust Proof/Earthquake Resistant/Waterproof/Heat Insulated

Material : Q195/Q235/Q345

Size : L5800mm × W5980mm × H2580mm

Weight : Approximately 4000kg

Flooring : Laminate board (18mm)

Windows : Aluminum windows

Door : Steel door

Wall Material : 75mm sandwich panel

Name : T Model Prefab House

Contact Now

Energy Efficient Prefab House Fast Assembly Weather Resistant Residential Living Space
Lida prefab house (prefabricated house) is constructed using light steel framing for the structure and insulated sandwich panels for walls and roofing. The sandwich panels are available in various insulation materials including polystyrene, polyurethane, rock wool, and fiber glass.
The standard K model prefab house features modular construction with 1.8-meter sections connected by bolts. This design allows for assembly and disassembly more than 6 times, with a service life exceeding 15 years.
Technical Specifications
Type T Model Prefabricated House
House Depth 5.56m, 6.23m, 8.28m or custom sizes available
House Width N × K × 1.8m (where N = 5,6,7,... and K = 1.8m)
House Height Single floor, double floor, or three floors
Design Load Roof load: 0.50 KN/m²
Wind load: 0.45 KN/m²
Floor load: 1.5 KN/m²
Snow load: 0.15 KN/m²
Service Life 10-15 years
Main Column C section steel
Roof Truss C section steel
Roof & Wall Purlin C section steel
Roof Panel EPS, fiber glass, rock wool, or PU sandwich panel
Wall Panel EPS, fiber glass, rock wool, or PU sandwich panel
Window PVC window, aluminum alloy window, or custom options
Door Sandwich panel door, wood door, PVC door with glass, aluminum alloy frame door, security door, or custom options
Floor Plywood 18mm high-quality plywood
Floor Leather 1.5mm PVC floor leather
Electric System Sockets, switches, lights, cables, and accessories
Plumbing System Pipes, basin, toilet, and connection accessories
Installation Accessories Glass glue, nails, edge cover, AC rack, general bolts, anchor bolts, and installation components
Product Images
5.56m 6.23m T Model Prefab House C Section Prefab Steel Homes 5.56m 6.23m T Model Prefab House C Section Prefab Steel Homes
